Eaton Cutler-Hammer ATDR2-1/4 - Class CC Fuse 2A 600V (200kA AIC)

Eaton Cutler-Hammer ATDR2-1/4 is a low voltage current-limiting fuse from the Amp-Trap 2000 family, engineered to provide superior short-circuit protection for sensitive electrical components. It features a 2A current rating and a 600V AC voltage rating, capable of interrupting up to 200kA. The fuse is constructed as a single-barrel, 1-1/2 inch long device with a 0.41-inch diameter and a weight of 0.02 lb, conforming to Class CC dimensions. It is UL and CSA certified, ensuring compliance with rigorous industry safety and performance standards. This fuse is typically applied in industrial control circuits, motor branch circuits, and transformer protection where high interrupting capacity and current limitation are critical.

Key Features & Specifications

• Type: ATDR, Class CC, current-limiting, low voltage fuse, single barrel
• Voltage Rating: 600V AC
• Current Rating: 2A
• Dimensions: 1-1/2 in length, 0.41 in diameter
• Standards: UL/CSA Certified
• Applications: Industrial control circuits, motor branch circuits, transformer protection
• AIC rating: 200kA @ 600V AC
• Class Rating: CC
• Barrels: 1
• Weight: 0.02 lb
• Family: Amp-Trap 2000
• Country of Origin: Mexico

Product Identification

• UPC: 782001908522
• GTIN: 00782001908522
