Eaton Cutler-Hammer ATDR17-1/2 - Class CC Fuse 17.5A 600V (200kA AIC)

Eaton Cutler-Hammer ATDR17-1/2 is a Class CC low-voltage current-limiting fuse designed for circuit protection in industrial electrical systems. It provides 17.5A current protection with a 600V AC voltage rating and features a compact 1-1/2 inch body length with 0.41 inch diameter. The fuse meets UL/CSA certification standards and offers 200kA interrupting capacity at 600V AC for reliable fault protection. Typical applications include protection of control circuits, transformers, and motor circuits where high interrupting capacity and current limitation are required.

Key Features & Specifications

• Type: Class CC current-limiting fuse, single barrel construction
• Voltage Rating: 600V AC
• Current Rating: 17.5A
• Dimensions: 1-1/2 inch length, 0.41 inch diameter
• Standards: UL/CSA certified
• Applications: Control circuits, transformers, motor circuit protection
• AIC rating: 200kA@600V AC
• Class Rating: CC
• Barrels: 1
• Weight: 0.02 lb
• Family: Amp-Trap 2000
• Country of Origin: Mexico

Product Identification

• UPC: 782001901981
• GTIN: 00782001901981
