Eaton Cutler-Hammer ATDR1-1/2 - Class CC Fuse 1A 600V (200kA AIC Rating)

Eaton Cutler-Hammer ATDR1-1/2 is a current-limiting fuse designed for protecting sensitive electrical components and conductors in industrial power distribution systems. It features a 1A current rating and 600V AC voltage rating with a high 200kA interrupting capacity at 600V for reliable circuit protection. The fuse measures 1-1/2 inches in length with a 0.41-inch diameter and weighs 5 lb, constructed as a single-barrel Class CC fuse. It carries UL/CSA certification and meets industry standards for safety and performance. Typical applications include motor control centers, industrial control panels, and branch circuit protection where current limitation is critical.

Key Features & Specifications

• Type: Current-limiting time-delay fuse, single barrel construction
• Voltage Rating: 600V AC
• Current Rating: 1A
• Dimensions: 1-1/2 inch length, 0.41 inch diameter
• Standards: UL/CSA certified
• Applications: Motor control centers, industrial control panels, branch circuit protection
• AIC rating: 200kA@600V
• Class Rating: CC
• Barrels: 1
• Weight: 5 lb
• Family: Amp-Trap 2000
• Country of Origin: Mexico

Product Identification

• UPC: 782001908508
• GTIN: 00782001908508
