Cutler-Hammer AG40 - Class G Fuse 40A 480V (100kA AIC Rating)
Regular price
$8.67
$8.67
Regular price
$220.83
$220.83
Sale price
$8.67
$8.67
Save $212.16
/
- In stock, ready to ship
- Backordered, shipping soon
The Cutler-Hammer AG40 is a Class G low-voltage current-limiting fuse designed to provide reliable overcurrent protection for industrial electrical systems. It features a 40A current rating and 480V voltage rating with a high interrupting capacity of 100kA at 480V AC. The fuse construction includes a single-barrel design measuring 2-1/4" in length with a 0.41" diameter and weighs 5 lb, utilizing current-limiting technology to protect against short circuits. It complies with CSA certification to C22.2 No. 248.5 and UL Standard 248-5 requirements. Typical applications include motor branch circuit protection, feeder circuit protection, and industrial control panel applications where Class G fuse protection is specified.
Key Features & Specifications
Product Identification
Key Features & Specifications
- Type: Class G low-voltage current-limiting fuse, single barrel
- Voltage Rating: 480V AC
- Current Rating: 40A
- Dimensions: 2-1/4" length, 0.41" diameter
- Standards: CSA Certified to C22.2 No. 248.5, UL Listed 248-5
- Applications: Motor branch circuit protection, feeder circuits, industrial control panels
- AIC rating: 100kA@480V
- Class Rating: G
- Barrels: 1
- Weight: 5 lb
- Family: Amp-Trap
Product Identification
- UPC: 782001905194
- GTIN: 00782001905194
