Cutler Hammer AG4 - Class G Fuse 4A 600V (100kA AIC Rating)

Cutler Hammer AG4 is a Class G low-voltage current-limiting fuse designed for comprehensive circuit protection in industrial applications. It provides reliable overcurrent protection with a 4A current rating and 600V voltage rating, featuring a compact single-barrel construction measuring 1.31 inches in length with a 0.41-inch diameter. The fuse meets rigorous safety standards including CSA certification to C22.2 No. 248.5 and UL Listing 248-5, ensuring compliance with industry requirements. Typical applications include motor branch circuits, transformer protection, and industrial control panels where high interrupting capacity is essential.

Key Features & Specifications

• Type: Class G current-limiting fuse, single barrel construction
• Voltage Rating: 600V AC
• Current Rating: 4A
• Dimensions: 1.31 inches length, 0.41 inches diameter
• Standards: CSA Certified to C22.2 No. 248.5, UL Listed 248-5
• Applications: Motor branch circuits, transformer protection, industrial control panels
• AIC rating: 100kA@600V
• Class Rating: G
• Barrels: 1
• Weight: 0.02 lb
• Family: Amp-Trap
• Country of Origin: Mexico

Product Identification

• UPC: 78200190509
• GTIN: 00782001905095
