Eaton Cutler-Hammer AG35 - Class G Fuse 35A 480V (100kA AIC Rating)

Eaton Cutler-Hammer AG35 is a Class G low-voltage current-limiting fuse designed for circuit protection in industrial applications. It features a 35A current rating and 480V voltage rating with a high interrupting capacity of 100kA. The fuse measures 2-1/4" in length with a 0.41" diameter and utilizes a single-barrel construction. It meets CSA C22.2 No. 248.5 and UL 248-5 standards for safety and performance. Typical applications include motor branch circuits, feeder circuits, and industrial control panels where reliable overcurrent protection is required.

Key Features & Specifications

• Type: Class G current-limiting fuse, single barrel construction
• Voltage Rating: 480V AC
• Current Rating: 35A
• Dimensions: 2-1/4" length x 0.41" diameter
• Standards: CSA Certified to C22.2 No. 248.5, UL Listed 248-5
• Applications: Motor branch circuits, feeder circuits, industrial control panels
• AIC rating: 100kA@480V
• Class Rating: G
• Barrels: 1
• Weight: 0.03 lb
• Family: Amp-Trap
• Country of Origin: Mexico

Product Identification

• UPC: 782001905187
• GTIN: 00782001905187
