Mersen AG1-1/2 - Class G Fuse 1A 600V (100kA AIC Rating)

Mersen AG1-1/2 is a Class G low-voltage current-limiting fuse designed for comprehensive circuit protection in industrial applications. It features a 1A current rating and 600V AC voltage rating with a high interrupting capacity of 100kA, providing reliable overcurrent protection. The fuse construction includes a single-barrel design with 0.41-inch diameter and 1.31-inch length, weighing 0.02 lb for compact installation. It meets CSA C22.2 No. 248.5 and UL 248-5 standards, ensuring compliance with industrial safety requirements. Typical applications include motor branch circuits, transformers, and feeder circuits where precise current limitation is critical.

Key Features & Specifications

• Type: Class G current-limiting fuse, single-barrel construction
• Voltage Rating: 600V AC
• Current Rating: 1A
• Dimensions: 0.41" diameter x 1.31" length
• Standards: CSA Certified to C22.2 No. 248.5, UL Listed 248-5
• Applications: Motor protection, transformer circuits, industrial feeders
• AIC rating: 100kA@600V
• Class Rating: G
• Barrels: 1
• Diameter: 0.41 inches
• Weight: 0.02 lb
• Certification: CSA, UL
• Family: Amp-Trap
• Country of Origin: Mexico

Product Identification

• UPC: 782001905064
• GTIN: 00782001905064
