Cutler-Hammer ACL30 - Current-Limiting Fuse 30A 125V (100kA AIC Rating)

The Cutler-Hammer ACL30 is a low-voltage current-limiting fuse designed for circuit protection in industrial electrical systems. This 30A rated fuse operates at 125V AC with a high interrupting capacity of 100kA, providing reliable short-circuit protection. Constructed with a single-barrel design and forklift-style terminals, the fuse features a compact 1-inch diameter configuration weighing 1 lb for straightforward installation. Engineered to meet industry standards for safety and performance, this fuse is commonly deployed in motor control centers, industrial control panels, and power distribution equipment where robust circuit protection is essential.

Key Features & Specifications

• Type: Current-limiting low-voltage fuse, single-barrel construction
• Voltage Rating: 125V AC
• Current Rating: 30A
• Dimensions: 1-inch diameter
• Standards: Industrial safety standards compliance
• Applications: Motor control centers, industrial control panels, power distribution equipment
• AIC Rating: 100kA@125V
• Connection: Forklift style
• Barrels: 1
• Weight: 1 lb

Product Identification

• UPC: 782001791377
• GTIN: 00782001791377
