Cutler Hammer A70QS90-4 - Amp-Trap Low Voltage Fuse 90A (200kA AIC @ 700V)

The Cutler Hammer A70QS90-4 is a 90A low voltage current-limiting fuse from the Amp-Trap family, engineered to provide superior short-circuit protection in demanding electrical systems. It features a 700V AC voltage rating and an impressive 200kA interrupting capacity at this voltage, ensuring reliable circuit interruption under extreme fault conditions. The fuse is constructed as a single-barrel unit with a 1-inch diameter and a robust design weighing 5.19 lb, built to withstand industrial environments. It complies with relevant industry standards for safety and performance, making it suitable for protecting motor circuits, feeders, and branch circuits in industrial control panels and power distribution equipment.

Key Features & Specifications

• Type: Amp-Trap A70QS, Low Voltage Current-Limiting Fuse, Single Barrel
• Voltage Rating: 700V AC
• Current Rating: 90A
• Dimensions: 1 inch Diameter
• Standards: Industry Standard for Low Voltage Fuses
• Applications: Motor Circuit Protection, Feeder Protection, Branch Circuit Protection, Industrial Control Panels, Power Distribution
• AIC rating: 200kA @ 700V AC
• Weight: 5.19 lb

Product Identification

• UPC: 78200194866
• GTIN: 00782001948665
