Cutler Hammer A70Q250-4 - Low Voltage Fuse 250A (700V, 100kA AIC)

Cutler Hammer A70Q250-4 is a low voltage current-limiting fuse from the Amp-Trap family designed to provide superior short-circuit protection for industrial electrical systems. It features a 250A current rating and a 700V AC voltage rating, housed in a robust 2-inch diameter single-barrel construction with a weight of 1 lb. This fuse is UL certified and engineered to deliver a 100,000A interrupting rating at 700V, ensuring compliance with stringent industry safety standards for reliable operation in demanding environments such as motor control centers, industrial control panels, and power distribution equipment.

Key Features & Specifications

• Type: Amp-Trap A70Q, current-limiting, low voltage fuse
• Voltage Rating: 700V AC
• Current Rating: 250A
• Dimensions: 2-inch diameter
• Standards: UL Certified
• Applications: Motor control centers, industrial control panels, power distribution equipment
• AIC rating: 100kA @ 700V AC
• Fuse Class: Low Voltage
• Barrels: 1
• Weight: 1 lb

Product Identification

• UPC: 782001140991
• GTIN: 00782001140991
