Cutler Hammer A70Q125-4 - Low Voltage Fuse 125A (100kA AIC @ 700V)

The Cutler Hammer A70Q125-4 is a low-voltage current-limiting fuse designed to provide reliable overcurrent and short-circuit protection in industrial electrical systems. It features a 125A current rating and a 700V AC voltage rating, capable of interrupting faults up to 100kA. The fuse is constructed as a single-barrel unit with a 1.5-inch diameter and a 5.09-inch length, weighing 5.19 lb for robust physical durability. This component is certified to UL standards (Guide JFHR2, File E60314) and carries CE marking, ensuring compliance with stringent industry safety requirements. It is typically applied in motor control centers, industrial control panels, and power distribution systems where high-interrupting capacity is critical.

Key Features & Specifications

• Type: Low Voltage, Current-Limiting Fuse, Single Barrel
• Voltage Rating: 700V AC
• Current Rating: 125A
• Dimensions: 5.09 in Length, 1.5 in Diameter
• Standards: UL Recognized (Guide JFHR2, File E60314), CE
• Applications: Industrial Control Panels, Motor Control Centers, Power Distribution
• AIC rating: 100kA @ 700V
• Certification: CE, UL Recognized
• Barrels: 1
• Weight: 5.19 lb
• Country of Origin: Mexico

Product Identification

• UPC: 078200114095
• GTIN: 00782001140953
