Cutler Hammer A70P1500-4 - Amp-Trap Current-Limiting Fuse 1500A (100kA AIC @ 700V)

Cutler Hammer A70P1500-4 is a low voltage current-limiting fuse from the Amp-Trap family designed to provide superior short-circuit protection in industrial electrical systems. It features a 1500A current rating and a 700V voltage rating, capable of interrupting faults up to 100kA at its rated voltage. The fuse is constructed with a single-barrel design, measures 3.5 inches in diameter, weighs 18 lb, and utilizes a robust bolt-in blade connection for secure installation. This fuse is engineered to meet rigorous industrial standards for reliable performance in demanding environments, making it suitable for protecting motor control centers, industrial control panels, and power distribution equipment.

Key Features & Specifications

• Type: Amp-Trap A70P, Low Voltage Current-Limiting Fuse, Single Barrel
• Voltage Rating: 700V AC
• Current Rating: 1500A
• Dimensions: 3.5" Diameter
• Standards: Industrial Standards for Short-Circuit Protection
• Applications: Motor Control Centers, Industrial Control Panels, Power Distribution Equipment
• AIC rating: 100kA @ 700V
• Connection: Bolt-In Blade
• Barrels: 1
• Weight: 18 lb

Product Identification

• UPC: 078200194704
• GTIN: 00782001947040
