Cutler Hammer A6Y800-5 - Class K Fuse 800A (200kA AIC @ 600V)

Cutler Hammer A6Y800-5 is a low voltage current-limiting fuse from the Amp-Trap family designed to provide reliable overcurrent and short-circuit protection in industrial electrical systems. It features a 600V AC voltage rating and an 800A current rating, capable of interrupting faults with a 200kA AIC rating at 600V. The fuse is constructed as a single-barrel Class K unit with a 3-inch diameter and a hinged connection, weighing 10 lb for robust physical integrity. This fuse complies with industry standards for current-limiting protection, ensuring enhanced system safety by reducing let-through energy. It is typically applied in motor control centers, industrial control panels, and feeder circuits where high-level fault protection is critical.

Key Features & Specifications

• Type: Amp-Trap A6Y, Low Voltage Current-Limiting Fuse, Single Barrel
• Voltage Rating: 600V AC
• Current Rating: 800A
• Dimensions: 3-inch Diameter
• Standards: Class K
• Applications: Motor Control Centers, Industrial Control Panels, Feeder Circuits
• AIC rating: 200kA @ 600V
• Connection: Hinge
• Barrels: 1
• Weight: 10 lb

Product Identification

• UPC: 782001909536
• GTIN: 00782001909536
