Ferraz Shawmut A6Y70-4 - Class K Fuse 70A (200kA@600V Interrupt Rating)

Ferraz Shawmut A6Y70-4 is a low-voltage current-limiting fuse from the Amp-Trap family, designed for circuit protection in industrial electrical systems. It features a 600V AC rating with a 70A current capacity and a 200kA interrupting rating at 600V for reliable short-circuit protection. The compact 1-inch diameter plug-in design with a single barrel construction ensures easy installation in compatible fuse holders. Compliant with Class K standards, this fuse is engineered for demanding applications including motor control centers, switchgear, and power distribution panels where high fault current interruption is critical.

Key Features & Specifications

• Type: Class K current-limiting fuse, single-element design with quartz sand filler
• Voltage Rating: 600V AC
• Current Rating: 70A
• Dimensions: 1" diameter, plug-in configuration
• Standards: UL/CSA Class K
• Applications: Motor protection, switchgear, industrial power distribution
• AIC rating: 200kA@600V
• Connection: Plug-In
• Barrels: 1
• Weight: 1 lb

Product Identification

• UPC: 782001904951
• GTIN: 00782001904951
