Ferraz Shawmut A6Y600-5 - Class K Fuse 600A 600V (200kA AIC)

Ferraz Shawmut A6Y600-5 is a low-voltage fuse from the Amp-Trap family designed for high-current circuit protection in industrial applications. This Class K fuse features a 600V AC rating and 600A current capacity with a 200kA interrupting rating at 600V for reliable fault protection. The compact 2.5-inch diameter unit utilizes a robust single-barrel hinge connection design weighing 5 lb, meeting stringent industry standards for electrical safety. Its construction ensures compliance with UL/ANSI fuse requirements for industrial power distribution systems. Typical applications include motor control centers, switchgear, and heavy equipment protection where high interrupting capacity is critical.

Key Features & Specifications

• Type: Class K Amp-Trap low-voltage current-limiting fuse (A6Y series)
• Voltage Rating: 600V AC
• Current Rating: 600A
• Dimensions: 2.5" diameter
• Standards: UL/ANSI compliant
• Applications: Industrial power distribution, MCCs, switchgear
• AIC rating: 200kA@600V
• Connection: Hinge type
• Barrels: 1
• Weight: 5 lb
• Class Rating: K

Product Identification

• UPC: 782001908317
• GTIN: 00782001908317
