Cutler Hammer A6Y500-5 - Class K Current-Limiting Fuse 500A (200kA AIC @600V)

Cutler Hammer A6Y500-5 is a Class K low-voltage current-limiting fuse from the Amp-Trap family, designed to provide superior short-circuit protection for electrical distribution systems. It features a 500A current rating and a 600V AC voltage rating, with an impressive 200kA interrupting capacity at 600V to safely clear high-level faults. The fuse is constructed with a single-barrel design featuring a hinged connection and measures 2.5 inches in diameter with a weight of 5 lb for robust industrial service. This fuse complies with industry standards for Class K current-limiting fuses, ensuring reliable protection for motor control centers, service entrance equipment, and industrial power distribution panels where high fault current protection is critical.

Key Features & Specifications

• Type: Class K Amp-Trap current-limiting fuse, single barrel with hinged connection
• Voltage Rating: 600V AC
• Current Rating: 500A
• Dimensions: 2.5" diameter
• Standards: Class K current-limiting fuse standards
• Applications: Motor control centers, service entrance equipment, industrial power distribution
• AIC Rating: 200kA@600V
• Connection: Hinge
• Barrels: 1
• Class Rating: K
• Weight: 5 lb

Product Identification

• UPC: 782001908270
• GTIN: 00782001908270
