Cutler Hammer A6Y500-3 - Class K Fuse 500A (200kA AIC @ 600V)

Cutler Hammer A6Y500-3 is a Class K low-voltage fuse from the Amp-Trap family designed to provide reliable overcurrent protection in industrial power distribution systems. It features a 500A current rating and a 600V AC voltage rating, with a high 200kA interrupting capacity at 600V to safely clear severe fault currents. The fuse is constructed as a single-barrel, plug-in type unit with a 2.5-inch diameter and weighs 5 lb, engineered for robust performance in demanding environments. It complies with industry standards for Class K fuses, ensuring consistent protection characteristics. Typical applications include motor control centers, panelboards, and switchboards where high-interrupting capacity protection is required.

Key Features & Specifications

• Type: Class K Amp-Trap low-voltage current-limiting fuse, plug-in connection, single barrel
• Voltage Rating: 600V AC
• Current Rating: 500A
• Dimensions: 2.5-inch diameter
• Standards: Class K fuse standards
• Applications: Industrial power distribution, motor control centers, panelboards, switchboards
• AIC rating: 200kA @ 600V AC
• Connection: Plug-In
• Barrels: 1
• Class Rating: K
• Weight: 5 lb

Product Identification

• UPC: 782001907952
• GTIN: 00782001907952
