Cutler Hammer A6Y30-2SG - Class K Time-Delay Fuse 30A (200kA AIC @ 600V)

Cutler Hammer A6Y30-2SG is a low voltage current-limiting fuse from the Amp-Trap family designed to provide superior short-circuit protection for industrial electrical systems. It features a 30A current rating and a 600V AC voltage rating, capable of interrupting faults up to 200kA. The fuse is constructed as a single-barrel unit with a Class K time-delay rating and a compact 0.81-inch diameter, weighing 5.19 lb for robust physical handling. This fuse complies with industry standards for current-limiting protection, making it suitable for a wide range of applications including motor branch circuits, feeders, and industrial control panels where reliable fault interruption is critical.

Key Features & Specifications

• Type: Amp-Trap A6Y, Low Voltage Current-Limiting Fuse, Time-Delay
• Voltage Rating: 600V AC
• Current Rating: 30A
• Dimensions: 0.81 inch Diameter
• Standards: Class K
• Applications: Motor Branch Circuits, Feeders, Industrial Control Panels
• AIC rating: 200kA @ 600V
• Barrels: 1
• Class Rating: K
• Weight: 5.19 lb

Product Identification

• UPC: 78200190205
• GTIN: 00782001902056
