Cutler Hammer A6Y3-1R - Class K Fuse 3A 500V (200kA AIC)

Cutler Hammer A6Y3-1R is a Class K low-voltage current-limiting fuse from the Amp-Trap family, engineered to provide superior short-circuit protection for electrical circuits and equipment. It features a 3A current rating and a 500V AC voltage rating, with a high 200kA interrupting capacity at its rated voltage to safely clear severe fault conditions. The fuse is constructed with a single-barrel design featuring ferrule connections and measures 0.81 inches in diameter, contributing to a robust and compact form factor. It is designed to meet industry standards for current-limiting fuses, ensuring reliable performance and equipment safety. Typical applications include the protection of motor circuits, transformers, and feeders in industrial and commercial power distribution systems.

Key Features & Specifications

• Type: Class K, Amp-Trap, Current-Limiting, Low-Voltage Fuse
• Voltage Rating: 500V AC
• Current Rating: 3A
• Dimensions: 0.81" Diameter
• Standards: Industry Standards for Current-Limiting Fuses
• Applications: Protection of Motor Circuits, Transformers, Feeders
• AIC rating: 200kA @ 500V
• Connection: Ferrule
• Barrels: 1
• Class Rating: K
• Family: Amp-Trap

Product Identification

• UPC: 78200190213
• GTIN: 00782001902131
