Cutler Hammer A6Y25-11 - Class K Current-Limiting Fuse 25A 600V (200kA AIC)

Cutler Hammer A6Y25-11 is a low voltage current-limiting fuse from the Amp-Trap family designed to provide reliable overcurrent and short-circuit protection in industrial electrical systems. It features a 25A current rating and a 600V AC voltage rating, ensuring robust performance under demanding conditions. The fuse is constructed with a single-barrel, ferrule non-rejection design measuring 1.5 inches in diameter and weighing 5.19 lb, utilizing a Class K construction for general purpose applications. This fuse complies with industry standards for current-limiting protection, achieving a 200kA interrupting rating at 600V AC. Typical applications include motor branch circuits, feeder circuits, and industrial control panels where superior short-circuit protection is required.

Key Features & Specifications

• Type: Amp-Trap current-limiting fuse, Class K, single barrel, ferrule non-rejection
• Voltage Rating: 600V AC
• Current Rating: 25A
• Dimensions: 1.5" diameter
• Standards: Class K current-limiting fuse
• Applications: Motor branch circuits, feeder circuits, industrial control panels
• AIC rating: 200kA@600V AC
• Connection: Ferrule Non-Rejection
• Barrels: 1
• Velocity: GP - General Purpose
• Class Rating: K
• Weight: 5.19 lb

Product Identification

• UPC: 78200190193
• GTIN: 00782001901936
