Cutler Hammer A6D6/10R - Class RK1 Fuse 6A 600V (200kA AIC Rating)

The Cutler Hammer A6D6/10R is a Class RK1 low-voltage current-limiting fuse designed to provide reliable overcurrent protection in industrial electrical systems. It features a 600V AC/DC voltage rating with a 6A current rating and offers exceptional 200kA interrupting capacity at 600V for high-fault current protection. The fuse construction utilizes a single-barrel design measuring 5 inches in length with a 0.81-inch diameter and weighs 5.19 lb, built to Eaton's Amp-Trap 2000 family specifications. This fuse meets rigorous certification standards including CSA C22.2 No. 248.12, UL 248, and UL 248-12 File E2137, ensuring compliance with industrial safety requirements. Typical applications include motor branch circuits, transformer protection, and feeder circuits where current-limiting characteristics and high interrupting ratings are essential.

Key Features & Specifications

• Type: Class RK1 current-limiting fuse, single-barrel construction
• Voltage Rating: 600V AC/DC
• Current Rating: 6A
• Dimensions: 5" length, 0.81" diameter
• Standards: CSA C22.2 No. 248.12, UL 248, UL 248-12 File E2137
• Applications: Motor branch circuits, transformer protection, feeder circuits
• AIC rating: 200kA@600V
• Class Rating: RK1
• Barrels: 1
• Weight: 5.19 lb
• Family: Amp-Trap 2000
• Country of Origin: Mexico

Product Identification

• UPC: 782001991562
• GTIN: 00782001991562
