Cutler Hammer A50QS35-4 - Low Voltage Fuse 35A (200kA AIC @ 500V)

The Cutler Hammer A50QS35-4 is a low voltage current-limiting fuse designed to provide reliable overcurrent and short-circuit protection in industrial electrical systems. It features a 35A current rating and a 500V AC voltage rating, ensuring robust performance under demanding conditions. The fuse is constructed with a single-barrel design, measures 3.63 inches in length with a 1-inch diameter, and utilizes a bolt-in blade connection for secure installation. It complies with major industry standards including UL Recognition (Guide JFHR2, File 60314) and CSA certification (LR12636), and carries the CE mark. This fuse is typically applied in motor branch circuits, feeder circuits, and industrial control panels where its 200kA interrupting rating at 500V provides critical protection for electrical components.

Key Features & Specifications

• Type: Low Voltage Current-Limiting Fuse, Single Barrel, Bolt-In Blade Connection
• Voltage Rating: 500V AC
• Current Rating: 35A
• Dimensions: 3.63 in Length x 1 in Diameter
• Weight: 5.19 lb
• Standards: UL Recognized (Guide JFHR2, File 60314), CSA Certified (LR12636), CE
• Applications: Motor Branch Circuits, Feeder Circuits, Industrial Control Panels
• AIC Rating: 200kA @ 500V
• Connection: Bolt-In Blade
• Barrels: 1
• Certification: CE, UL Recognized, CSA Certified

Product Identification

• UPC: 78200114248
• GTIN: 00782001142483
