Cutler-Hammer A50P900-4 - Amp-Trap Fuse 900A (100kA AIC @ 500V)

The Cutler-Hammer A50P900-4 is a Class A50P Amp-Trap fuse designed to provide superior short-circuit protection in low-voltage power distribution systems. It features a 900A current rating and a 500V AC voltage rating, ensuring reliable operation under demanding electrical conditions. The fuse is constructed with a single-barrel design, measures 3 inches in diameter, weighs 4 lb, and utilizes a robust bolt-in blade connection for secure installation. This component is UL certified and boasts an impressive 100,000 Ampere Interrupting Capacity (AIC) at 500V, complying with rigorous industry safety standards. It is typically applied in industrial settings for protecting feeders, mains, and large branch circuits where high fault currents are present.

Key Features & Specifications

• Type: Class A50P Amp-Trap Fuse, Current Limiting, Single Barrel
• Voltage Rating: 500V AC
• Current Rating: 900A
• Dimensions: 3" Diameter
• Standards: UL Certified
• Applications: Feeder, Main, and Branch Circuit Protection in Low-Voltage Power Distribution
• Connection: Bolt-In Blade
• AIC rating: 100kA @ 500V
• Barrels: 1
• Weight: 4 lb
• Family: Amp-Trap
• Item Subcategory: Low Voltage

Product Identification

• GTIN: 00782001947866
