Cutler Hammer A4BX2500-GE - Class L Time-Delay Fuse 2500A 600V (Bolt-In)

Cutler Hammer A4BX2500-GE is a low voltage fuse designed for comprehensive circuit protection in demanding industrial applications. This 600V AC/DC rated fuse features a 2500A current rating with time-delay (TD) characteristics to handle temporary overloads while providing fast response to short-circuit faults. Constructed as a Class L bolt-in fuse, it features robust construction with a weight of 11 lb for secure installation in power distribution systems. The fuse complies with industry standards for reliable performance and is part of Eaton's Amp-Trap family, engineered specifically for industrial power distribution panels, motor control centers, and service entrance equipment where high interrupting capacity and selective coordination are critical.

Key Features & Specifications

• Type: Class L time-delay current-limiting fuse, bolt-in connection
• Voltage Rating: 600V AC/DC
• Current Rating: 2500A
• Dimensions: Standard Class L configuration
• Standards: Industry standard compliance for low voltage fuses
• Applications: Industrial power distribution, motor control centers, service entrance equipment
• Fuse Class: L
• Connection: Bolt-In
• Velocity: TD - Time Delay
• Weight: 11 lb
• Family: Amp-Trap

Product Identification

• UPC: 78200193873
• GTIN: 00782001938734
