Mersen A480R2R-1 - Medium Voltage Fuse 4800V/70A (65kA AIC @4.8kV)

Mersen A480R2R-1 is a medium voltage fuse designed for high-current protection in industrial power systems. This Amp-Trap series fuse features a 4800V voltage rating and 70A current rating, housed in a robust 3-inch diameter single-barrel design with Class R interruption capability. It meets UL certifications (E93367, E191980) and delivers 65kA interrupting capacity at 4.8kV for reliable fault protection. The fuse is engineered for demanding applications including motor control centers, transformers, and feeder circuits in medium voltage distribution systems.

Key Features & Specifications

• Type: Medium voltage current-limiting fuse with Class R interruption
• Voltage Rating: 4800V AC
• Current Rating: 70A
• Dimensions: 3" diameter, 12.5" clip center spacing
• Standards: UL File E93367 (Amp-Trap), UL File E191980 (9F60)
• Applications: Motor protection, transformer circuits, industrial feeders
• AIC rating: [email protected]
• Class Rating: R
• Barrels: 1
• Weight: 11 lb

Product Identification

• UPC: 782001800703
• GTIN: 00782001800703
