Ferraz Shawmut A2Y200-4 - Low Voltage Fuse 200A@250V (200kA AIC)

Ferraz Shawmut A2Y200-4 is a low-voltage current-limiting fuse designed for circuit protection in industrial power distribution systems. This 200A blade-style fuse operates at 250V AC with a 200kA interrupting capacity, featuring a compact 1.5-inch diameter cylindrical design with single-barrel construction. UL Recognized under Component File E60314 and tested to UL248-1 standards (1-600A), it provides reliable overcurrent protection for motor control centers, switchgear, and industrial control panels.

Key Features & Specifications

• Type: Amp-Trap series current-limiting fuse with silver-sand construction
• Voltage Rating: 250V AC
• Current Rating: 200A
• Dimensions: 1.5" diameter, single-barrel blade connection
• Standards: UL Recognized (E60314), UL248-1 compliant (1-600A)
• Applications: Motor protection, switchgear, industrial control panels
• AIC rating: 200kA@250V
• Connection: Blade terminal
• Weight: 2 lb
• Certification: DC tested per UL248-1

Product Identification

• UPC: 78200190618
• GTIN: 00782001906184
