Cutler Hammer A2D80R - RK1 Class Fuse 80A 250V (200kA AIC Rating)

Cutler Hammer A2D80R is a low voltage current-limiting fuse designed for comprehensive circuit protection in industrial applications. This RK1 class fuse features a 80A current rating and 250V voltage rating with exceptional 200kA interrupting capacity, providing reliable short-circuit protection. The single-barrel construction measures 1.06 inches in diameter with a compact 5-7/8 inch length and weighs 0.31 lb, engineered for durable performance in demanding environments. It complies with CSA C22.2 No. 248.12, DC UL 248, and UL 248-12 standards (File E2137), ensuring adherence to industry safety requirements. Typical applications include motor branch circuits, feeder circuits, and industrial control panels where high-interrupting capacity protection is essential.

Key Features & Specifications

• Type: A2D-R current-limiting fuse, RK1 class, single barrel construction
• Voltage Rating: 250V AC/DC
• Current Rating: 80A
• Dimensions: 1.06" diameter x 5-7/8" length
• Weight: 0.31 lb
• Standards: CSA C22.2 No. 248.12, DC UL 248, UL 248-12 File E2137
• Applications: Motor branch circuits, feeder circuits, industrial control panels
• AIC rating: 200kA@250V
• Class Rating: RK1
• Barrels: 1
• Family: Amp-Trap 2000
• Item Subcategory: Low Voltage Fuse
• Country of Origin: Mexico

Product Identification

• UPC: 782001990992
• GTIN: 00782001990992
