Cutler Hammer A2D35R - Class RK1 Fuse 35A 250V (200kA AIC Rating)

The Cutler Hammer A2D35R is a Class RK1 low-voltage current-limiting fuse designed to provide superior short-circuit protection for industrial electrical systems. It features a 35A current rating and 250V voltage rating with an impressive 200kA interrupting capacity at rated voltage, ensuring reliable fault protection. The fuse construction includes a single-barrel design measuring 3" in length with 0.81" diameter and weighs 0.14 lb, utilizing current-limiting technology to prevent let-through energy during fault conditions. This fuse meets rigorous certification standards including CSA C22.2 No. 248.12, DC UL 248, and UL 248-12 File E2137, ensuring compliance with industry safety requirements. Typical applications include motor branch circuits, feeder circuits, and industrial control panels where high-interrupting capacity and current limitation are essential for system protection.

Key Features & Specifications

• Type: Class RK1 current-limiting fuse, single barrel design
• Voltage Rating: 250V AC/DC
• Current Rating: 35A
• Dimensions: 3" length, 0.81" diameter
• Standards: CSA C22.2 No. 248.12, DC UL 248, UL 248-12 File E2137
• Applications: Motor branch circuits, feeder circuits, industrial control panels
• AIC rating: 200kA@250V
• Class Rating: RK1
• Barrels: 1
• Weight: 0.14 lb
• Family: Amp-Trap 2000
• Country of Origin: Mexico

Product Identification

• UPC: 782001990909
• GTIN: 00782001990909
