Cutler Hammer A2D2-1/4R - RK1 Class Fuse 2A 250V (200kA AIC Rating)

The Cutler Hammer A2D2-1/4R is a low voltage current-limiting fuse from the Amp-Trap 2000 family, engineered to provide superior short-circuit protection for electrical circuits. It features a 2A current rating and a 250V voltage rating, capable of interrupting up to 200kA of fault current. The fuse is constructed as a single-barrel RK1 class device with a 0.56-inch diameter and a 2-inch length, weighing 5.19 lb. This component is certified to CSA C22.2 No. 248.12, DC UL 248, and UL 248-12 (File E2137) standards, ensuring reliable performance in demanding industrial applications such as motor branch circuits and feeder protection.

Key Features & Specifications

• Type: A2D-R, Low Voltage Current-Limiting Fuse, Single Barrel
• Voltage Rating: 250V AC/DC
• Current Rating: 2A
• Dimensions: 2" Length, 0.56" Diameter
• Weight: 5.19 lb
• Standards: CSA C22.2 No. 248.12, DC UL 248, UL 248-12 File E2137
• Applications: Motor Branch Circuits, Feeder Protection
• AIC rating: 200kA @ 250V
• Class Rating: RK1
• Barrels: 1
• Family: Amp-Trap 2000
• Country of Origin: Mexico

Product Identification

• UPC: 782001990572
• GTIN: 00782001990572
