Cutler Hammer A2D1/2R - Class RK1 Fuse 1A 250V (200kA AIC)

The Cutler Hammer A2D1/2R is a Class RK1 low-voltage current-limiting fuse from the Amp-Trap 2000 family, engineered to provide superior short-circuit protection for electrical circuits. It features a 1A current rating and a 250V AC voltage rating, with an impressive 200,000 AIC interrupting capacity to safely clear high-level faults. The fuse is constructed as a single-barrel unit with a 0.56-inch diameter and 2-inch length, contributing to a compact and robust design. It complies with stringent industry standards including UL 248-12 and CSA C22.2 No. 248.12, ensuring reliable performance in demanding industrial environments. This fuse is typically applied in motor control centers, industrial control panels, and feeder circuits where high interrupting capacity and current limitation are critical for system protection.

Key Features & Specifications

• Type: Class RK1, Amp-Trap 2000, Current-Limiting, Low Voltage Fuse
• Voltage Rating: 250V AC
• Current Rating: 1A
• Dimensions: 2" Length, 0.56" Diameter
• Standards: CSA C22.2 No. 248.12, DC UL 248, UL 248-12 File E2137
• Applications: Motor Control Centers, Industrial Control Panels, Feeder Circuits
• AIC rating: 200kA @ 250V
• Class Rating: RK1
• Barrels: 1
• Weight: 0.04 lb
• Family: Amp-Trap 2000
• Country of Origin: Mexico

Product Identification

• UPC: 782001990596
• GTIN: 00782001990596
