Cutler Hammer A150X20-1 - Amp-Trap Fuse 20A (1500V, 100kA AIC)

Cutler Hammer A150X20-1 is a low voltage current-limiting fuse from the Amp-Trap family designed to provide superior short-circuit protection in industrial electrical systems. It features a 20A current rating and a 1500V AC voltage rating, capable of interrupting faults up to 100,000 amperes. The fuse is constructed with a single-barrel design featuring ferrule connections and measures 0.81 inches in diameter with a weight of 5.19 lb. This fuse is engineered to meet rigorous industry standards for safety and performance in demanding applications. It is typically utilized for protecting motor circuits, feeders, and branch circuits in industrial control panels and power distribution equipment.

Key Features & Specifications

• Type: Amp-Trap A150X, Low Voltage Current-Limiting Fuse, Ferrule Connection, Single Barrel
• Voltage Rating: 1500V AC
• Current Rating: 20A
• Dimensions: 0.81 inches Diameter
• Standards: Industry standards for safety and performance
• Applications: Motor circuit protection, industrial feeders, branch circuits, control panels, power distribution
• AIC rating: 100kA @ 1500V
• Connection: Ferrule
• Barrels: 1
• Weight: 5.19 lb

Product Identification

• UPC: 78200194391
• GTIN: 00782001943912
