Ferraz Shawmut A150X1000-4 - Low Voltage Fuse 1000A@1500V (100kA AIC)

Ferraz Shawmut A150X1000-4 is a low-voltage fuse from the Amp-Trap family designed for high-current circuit protection in industrial applications. This bolt-in blade fuse features a 1000A current rating and 1500V voltage rating, with a robust 100kA@1500V interrupting capacity for reliable fault protection. Its single-barrel construction measures 3.5 inches in diameter and weighs 7 lb, engineered for durability in demanding environments. The fuse meets stringent industry standards for electrical safety and performance. Typical applications include power distribution systems, industrial machinery, and heavy equipment requiring high interrupting capacity.

Key Features & Specifications

• Type: Low-voltage current-limiting fuse with bolt-in blade connection
• Voltage Rating: 1500V AC
• Current Rating: 1000A
• Dimensions: 3.5" diameter
• Standards: UL/CSA certified
• Applications: Industrial power distribution, heavy machinery
• AIC rating: 100kA@1500V
• Connection: Bolt-In Blade
• Barrels: 1
• Weight: 7 lb
• Family: Amp-Trap

Product Identification

• UPC: 78200141127
• GTIN: 00782001411275
