General Electric 9F60MJD524 - EJ-2 Medium Voltage Fuse 450A@5080V (50kA AIC Rating)

General Electric 9F60MJD524 is a medium voltage fuse designed for high-capacity circuit protection in industrial power systems. This EJ-2 type fuse operates at 5080V with a 450A current rating, providing reliable overcurrent protection. The unit features a 3-inch diameter dual-barrel ferrule connection construction measuring 15.97 inches in length and weighing 2 lb, built to withstand demanding electrical environments. It meets Class R interrupting rating standards with a [email protected] AIC rating, ensuring compliance with industrial safety requirements. Typical applications include motor control centers, switchgear, and transformer protection in medium voltage distribution systems.

Key Features & Specifications

• Type: EJ-2 medium voltage fuse with dual-barrel ferrule connection
• Voltage Rating: 5080V AC
• Current Rating: 450A
• Dimensions: 15.97 inches length, 3-inch diameter
• Standards: Class R interrupting rating
• Applications: Industrial power systems, motor control centers, switchgear protection
• AIC rating: [email protected]
• Connection: Ferrule
• Barrels: 2
• Clip Center: 12 inches
• Weight: 2 lb
• Family: 9F60 Series
• Item Subcategory: Medium Voltage

Product Identification

• GTIN: 00782001396336
