General Electric 9F60MJD518 - EJ-2 Medium Voltage Fuse 390A@5080V (50kA AIC)

General Electric 9F60MJD518 is a medium voltage fuse designed for high-capacity circuit protection in industrial power systems. This EJ-2 type fuse operates at 5080V with a 390A current rating and provides 50kA interrupting capacity at 5.08kV for reliable fault protection. The unit features a robust R-class construction with dual ferrule barrel connection, 3-inch diameter, and standardized 12-inch clip center spacing for consistent mounting. Manufactured to meet industry standards for medium voltage applications, this fuse is typically deployed in industrial switchgear, motor control centers, and power distribution systems requiring dependable overcurrent protection.

Key Features & Specifications

• Type: EJ-2 medium voltage current-limiting fuse, R-class rating, dual ferrule barrel construction
• Voltage Rating: 5080V AC
• Current Rating: 390A
• Dimensions: 3" diameter, 12" clip center spacing
• Standards: Industry standard medium voltage fuse compliance
• Applications: Industrial switchgear, motor control centers, power distribution systems
• AIC rating: [email protected]
• Connection: Ferrule
• Barrels: 2
• Class Rating: R
• Weight: 2 lb
• Family: 9F60 Series
• Item Subcategory: Medium Voltage

Product Identification

• GTIN: 00782001396329
