General Electric 9F60MJD224 - Medium Voltage Fuse 24A 5080V (50kA AIC)

General Electric 9F60MJD224 is a medium-voltage current-limiting fuse designed for high-interruption capacity protection in industrial power systems. This Class R fuse features a 5080V voltage rating and 24A current rating, with a robust ferrule connection and dual-barrel construction for reliable arc quenching. The 3-inch diameter unit delivers 50kA interrupting capacity at 5.08kV, meeting stringent industry standards for medium-voltage circuit protection. Its 12-inch clip center spacing and 17 lb weight ensure compatibility with standard fuse holders while maintaining structural integrity. Typical applications include motor control centers, transformers, and feeder circuits requiring R-class protection.

Key Features & Specifications

• Type: Medium-voltage current-limiting fuse, Class R, dual-barrel design
• Voltage Rating: 5080V AC
• Current Rating: 24A
• Dimensions: 3" diameter, 12" clip center spacing
• Standards: Meets R-class interruption requirements
• Applications: Industrial power systems, MCCs, transformers
• AIC rating: [email protected]
• Connection: Ferrule
• Barrels: 2
• Weight: 17 lb
• Family: 9F60 Series
