General Electric 9F60LJN306 - EJ-2 Medium Voltage Fuse 170A@5080V (50kA AIC)

General Electric 9F60LJN306 is a medium voltage fuse designed for high-current circuit protection in industrial power systems. This EJ-2 class R fuse features a 5080V voltage rating and 170A current capacity, with a 50kA interrupting rating at 5.08kV for reliable fault protection. The ferrule-connected single-barrel design measures 3" in diameter with 12" clip centers, constructed for durability in demanding environments while meeting industry standards for medium voltage applications. Typical uses include motor protection, transformer circuits, and heavy industrial equipment where robust overcurrent protection is required.

Key Features & Specifications

• Type: EJ-2 class R medium voltage fuse with ferrule connection
• Voltage Rating: 5080V AC
• Current Rating: 170A
• Dimensions: 3" diameter, 12" clip center spacing
• Standards: Meets medium voltage fuse industry requirements
• Applications: Industrial motor circuits, transformer protection, power distribution
• AIC rating: [email protected]
• Connection: Ferrule
• Barrels: 1
• Class Rating: R
• Weight: 4 lb

Product Identification

• UPC: 782001396251
• GTIN: 00782001396251
