General Electric 9F60LCB506 - EJ-2 Class R Fuse 2400V/170A (50kA AIC)

General Electric 9F60LCB506 is a medium-voltage current-limiting fuse designed for industrial circuit protection in high-fault environments. This EJ-2 class R fuse features a 2400V AC rating with a 170A continuous current capacity and 50kA interrupting rating at 2.4kV, housed in a compact 3-inch diameter ferrule-connected barrel construction. The UL-certified (File E93367/E191980) fuse meets stringent Amp-Trap standards with 7-inch clip center spacing, providing reliable protection for medium-voltage distribution systems. Its 2 lb weight and rugged design make it suitable for switchgear, motor starters, and transformer protection in utility and industrial applications.

Key Features & Specifications

• Type: EJ-2 Class R current-limiting fuse
• Voltage Rating: 2400V AC
• Current Rating: 170A
• Dimensions: 3" diameter, 7" clip center
• Standards: UL File E93367 (Amp-Trap), UL File E191980 (9F60 Series)
• Applications: Medium-voltage switchgear, transformer protection
• AIC rating: [email protected]
• Connection: Ferrule
• Barrels: 1
• Weight: 2 lb
• Class Rating: R

Product Identification

• UPC: 782001396084
• GTIN: 00782001396084
