General Electric 9F60LCB504 - Medium Voltage Fuse 130A@2400V (Class R, 50kA AIC)

General Electric 9F60LCB504 is a medium voltage fuse designed for circuit protection in industrial power distribution systems. This EJ-2 type fuse operates at 2400V with a 130A current rating and provides 50kA interrupting capacity at 2.4kV for reliable fault protection. Constructed with a single-barrel ferrule connection and measuring 3 inches in diameter with 7-inch clip centers, the 2 lb unit features Class R construction for enhanced safety. The fuse complies with industry standards for medium voltage applications and is typically deployed in industrial plants, commercial facilities, and utility substations where robust circuit protection is required.

Key Features & Specifications

• Type: EJ-2 medium voltage fuse with Class R construction
• Voltage Rating: 2400V AC
• Current Rating: 130A
• Dimensions: 3" diameter, 7" clip centers
• Standards: Class R rated for medium voltage applications
• Applications: Industrial power distribution, commercial facilities, utility substations
• AIC rating: [email protected]
• Connection: Ferrule
• Barrels: 1
• Weight: 2 lb
• Class Rating: R

Product Identification

• GTIN: 00782001396077
