General Electric 9F60LCB503 - EJ-2 Medium Voltage Fuse (2400V AC, 100A)

General Electric 9F60LCB503 is a medium voltage fuse designed for circuit protection in industrial power distribution systems. This EJ-2 class R fuse features a 2400V AC rating with 100A current capacity and 50kA interrupting rating at 2.4kV, housed in a compact ferrule-connected design with 3" diameter and 7" clip center spacing. Constructed with durable materials, it meets industry standards for medium voltage applications including transformer protection and motor circuits. The single-barrel fuse weighs 2 lb and provides reliable overcurrent protection in demanding electrical environments.

Key Features & Specifications

• Type: EJ-2 class R medium voltage current-limiting fuse
• Voltage Rating: 2400V AC
• Current Rating: 100A
• Dimensions: 3" diameter, 7" clip center
• Standards: ANSI/IEEE C37.46
• Applications: Transformer protection, motor circuits, industrial power distribution
• AIC rating: [email protected]
• Connection: Ferrule
• Barrels: 1
• Weight: 2 lb
• Class Rating: R

Product Identification

• UPC: 078200139606
• GTIN: 00782001396060
