Schneider Electric 9080GH62 - Class J Fuse 600V AC/200A (200kA AIC)

Schneider Electric 9080GH62 is a current-limiting fuse designed for robust circuit protection in industrial power distribution systems. It features a 600V AC voltage rating and 200A current rating, with a compact cylindrical design constructed from durable ceramic housing and copper alloy elements for reliable fault interruption. The fuse meets UL/CSA standards for safety and performance in demanding environments. Typical applications include motor control centers, switchgear, and transformer protection where high interrupting capacity is required.

Key Features & Specifications

• Type: Current-limiting ceramic body fuse with sand-filled arc quenching
• Voltage Rating: 600V AC
• Current Rating: 200A
• Dimensions: 2.5" diameter x 4.75" length
• Standards: UL 248-12, CSA C22.2 No. 248.12
• Applications: Industrial switchgear, MCCs, transformer protection
• AIC Rating: 200kA
• Class Rating: Class J
• Operating Temperature: -40°C to 75°C
• Mounting: Bolt-on terminal connection

Product Identification

• UPC: 78590100078
• GTIN: 00785901000785
