Schneider Electric 9080FB3611R - Class J Fuse 600V/600A (200kA Interrupt Rating)

Schneider Electric 9080FB3611R is a current-limiting fuse designed for robust circuit protection in industrial power distribution systems. It features a 600V AC rating with a 600A current capacity, housed in a durable ceramic body with silver-plated copper end caps for optimal conductivity. The fuse meets UL 248-12 and IEC 60269 standards, ensuring reliable performance in high-fault environments. Its compact 76.2mm x 38.1mm dimensions make it suitable for panelboards and switchgear applications, particularly in manufacturing facilities and utility substations where short-circuit protection is critical.

Key Features & Specifications

• Type: Current-limiting Class J fuse with ceramic body and silver-plated contacts
• Voltage Rating: 600V AC
• Current Rating: 600A
• Dimensions: 76.2mm x 38.1mm (3" x 1.5")
• Standards: UL 248-12, IEC 60269 compliant
• Applications: Industrial switchgear, motor control centers, panelboard protection
• Interrupt Rating: 200kA symmetrical
• Operating Temperature: -40°C to 100°C
• Mounting: Bolt-on terminal connection
• Fuse Class: Class J
• Insulation Temperature: 125°C
• Certification: CSA, UL recognized
