Eaton 480G - Class J Fuse 480V AC (600A Current Rating)

Eaton 480G is a current-limiting fuse designed for robust circuit protection in industrial power distribution systems. It features a 480V AC voltage rating with current ratings up to 600A, housed in a durable cylindrical ceramic body with silver-sand filler for superior arc quenching. The fuse meets UL 248-12 and CSA standards for Class J fuses, ensuring reliable performance in demanding environments. Typical applications include motor branch circuits, transformer protection, and feeder protection in manufacturing facilities and power plants.

Key Features & Specifications

• Type: Class J current-limiting fuse with ceramic body and silver-sand filler
• Voltage Rating: 480V AC
• Current Rating: Up to 600A
• Dimensions: 1.5" diameter x 3.5" length
• Standards: UL 248-12, CSA certified
• Applications: Motor protection, transformer circuits, industrial feeders
• Fuse Class: Class J
• Interrupt Rating: 200kA
• Mounting: Bolt-on terminal connection
• Operating Temperature: -50°C to +125°C
• Enclosure: Non-inductive ceramic construction

Product Identification

• UPC: 662276018334
