Bussmann JM60030-3CR - Fuse Block 30A 600V (UL Listed IZLT)

The Bussmann JM60030-3CR is a 30A fuse block designed for secure electrical circuit protection in industrial applications. It features a 600V voltage rating and accommodates copper or aluminum conductors ranging from AWG 14 to AWG 2. The unit is constructed with a box lug and reinforced spring clip mounting system within compact dimensions of 3.30 x 3.40 x 2.30 inches and a weight of 1 lb. This fuse block complies with CE, CSA, RoHS, and UL standards (E14853 IZLT and IZLT7) and operates effectively across a temperature range of -25°C to 70°C (-13°F to 158°F). It is typically implemented in industrial control panels, motor branch circuits, and power distribution systems requiring reliable overcurrent protection.

Key Features & Specifications

• Type: Fuse Block with Box Lug and Reinforced Spring Clip Mounting
• Voltage Rating: 600V
• Current Rating: 30A
• Dimensions: 3.30 in x 3.40 in x 2.30 in
• Standards: CE, CSA Certified 47235-6225-01, RoHS Compliant, UL Listed E14853 IZLT and IZLT7
• Applications: Industrial control panels, motor branch circuits, power distribution
• Mounting: Box Lug With Clip Reinforced Spring
• Wire Size: AWG 14 to AWG 2, AWG 8 to AWG 2, Cu/Al
• Temp Rating: -25°C to 70°C (-13°F to 158°F)
• Weight: 1 lb
• Country of Origin: Mexico

Product Identification

• UPC: 051712514651
• GTIN: 00051712514651
