ITE FP32 - Fast-Acting Fuse Block 600V AC/32A (UL/CSA Certified)

ITE FP32 is a fast-acting fuse block designed for overcurrent protection in industrial electrical systems. It features a 600V AC/250V DC voltage rating with a 32A current capacity, housed in a durable ceramic body with compact dimensions (1.5" x 0.75" x 0.5") for space-efficient panel mounting. The fuse meets UL/CSA standards for safety and reliability in demanding environments. Typical applications include motor control centers, power distribution panels, and industrial machinery protection circuits.

Key Features & Specifications

• Type: Fast-acting ceramic fuse block with screw terminals
• Voltage Rating: 600V AC/250V DC
• Current Rating: 32A
• Dimensions: 1.5" x 0.75" x 0.5" (38.1mm x 19.05mm x 12.7mm)
• Standards: UL 248-14, CSA C22.2 No. 248.14
• Applications: Motor protection, power distribution, industrial control panels
• Mounting: Panel mount
• Terminal Connection: Screw-type
• Material: Ceramic body with copper alloy contacts
• Interrupt Rating: 100kA at 600V AC
• Operating Temperature: -40°C to +125°C

Product Identification

• UPC: 804766680885
