ABB HTDE258025 - Medium Voltage Fuse 25kA@23kV (80kA AIC Rating)

ABB HTDE258025 is a medium voltage fuse designed for high-current circuit protection in industrial power distribution systems. This Hi-Tech EXT series fuse features a 23kV voltage rating and 25kA current rating, with an 80kA interrupting capacity at full voltage for reliable fault isolation. The single-barrel construction utilizes an eyebolt/knurled stud connection system within a compact 2.2-inch diameter housing weighing 4 lb, engineered for 13.4-inch clip center installations. Compliant with international medium voltage protection standards, it's specifically developed for substation equipment, transformer protection, and heavy industrial applications requiring robust short-circuit protection.

Key Features & Specifications

• Type: HTDE medium voltage current-limiting fuse
• Voltage Rating: 23,000V AC
• Current Rating: 25,000A
• Dimensions: 2.2" diameter, 13.4" clip center
• Standards: IEEE/ANSI medium voltage protection
• Applications: Substations, industrial power distribution
• AIC rating: 80kA@23kV
• Connection: Eyebolt/Knurled Stud
• Barrels: 1
• Weight: 4 lb

Product Identification

• UPC: 78378650900
• GTIN: 00783786509003
