Cutler Hammer DH262FGK - Safety Disconnect Switch 60A 600V (200kA AIC NEMA 1)

Cutler Hammer DH262FGK is a heavy-duty safety disconnect switch designed for reliable circuit isolation and load break operations in industrial power distribution systems. This 600V AC rated switch handles 60A continuous current with a 200kA interrupting capacity, providing robust protection against short-circuit conditions. The unit features a compact 9x16x16 inch NEMA 1 enclosure constructed with UL Listed certification and NEC 230.62(C) compliant barriers for enhanced safety. Manufactured in the United States to meet rigorous industrial standards, this two-pole single configuration disconnect accommodates copper or aluminum conductors from AWG 14 to AWG 2. Typical applications include motor control centers, industrial machinery, and power distribution panels where safe maintenance and equipment isolation are critical.

Key Features & Specifications

• Type: Safety disconnect switch, DH Series, heavy-duty industrial construction
• Voltage Rating: 600V AC
• Current Rating: 60A
• Dimensions: 9 in x 16 in x 16 in (WxDxH)
• Standards: UL Listed, NEC 230.62(C) Compliant Barrier
• Applications: Industrial power distribution, motor control centers, machinery isolation
• Switch Type: Disconnect
• Configuration: Single
• Poles: 2
• AIC rating: 200kA@600V
• Nema Rating: NEMA 1
• Wire Size: AWG 14 to AWG 2, Cu/Al
• Compatible Frames: SEDA
• Weight: 18 lb
• Country of Origin: United States

Product Identification

• UPC: 782113205960
• GTIN: 00782113205960
