Siemens 48FM36X-6 - Medium Voltage Fuse 4800V 36A (Class R Ferrule Connection)

Siemens 48FM36X-6 is a medium voltage power fuse designed for circuit protection in industrial electrical systems. This Class R fuse operates at 4800V with a 36A current rating, providing reliable overcurrent protection for high-voltage applications. The fuse features a robust ferrule connection system with three barrels and measures 3 inches in diameter with 12-inch clip centers, constructed for durable performance in demanding environments. It complies with industry standards for medium voltage protection equipment and is typically deployed in industrial power distribution, motor control centers, and transformer protection circuits where high-interrupting capacity is required.

Key Features & Specifications

• Type: Medium Voltage Power Fuse, Class R, FM type with ferrule connection
• Voltage Rating: 4800V AC
• Current Rating: 36A
• Dimensions: 3" diameter, 12" clip center spacing
• Standards: Class R fuse classification
• Applications: Industrial power distribution, motor control centers, transformer protection
• Connection: Ferrule
• Barrels: 3
• Class Rating: R
• Weight: 33 lb
• Item Subcategory: Medium Voltage

Product Identification

• Manufacturer: Siemens/Allis Chalmers
• Model: 48FM36X-6
