Bussmann 17.5TDLSJ31.5 - Medium Voltage Fuse 31.5A ([email protected] Interrupting Capacity)

Bussmann 17.5TDLSJ31.5 is a medium voltage fuse designed for providing high-interrupting capacity protection in industrial power distribution systems. This DIN-type fuse operates at 17,500 volts with a 31.5 amp current rating and delivers 35.5 kA interrupting capacity at 17.5 kV for reliable circuit protection. The single-barrel construction features a 2-inch diameter with Class R rating and weighs 3 pounds for robust performance in demanding environments. Manufactured to international DIN standards, this fuse ensures compliance with industrial safety requirements. Typical applications include motor control centers, transformer protection, and medium voltage switchgear where high-performance circuit protection is essential.

Key Features & Specifications

• Type: DIN medium voltage fuse, single barrel construction
• Voltage Rating: 17,500V AC
• Current Rating: 31.5A
• Dimensions: 2-inch diameter
• Standards: DIN compliance
• Applications: Industrial power distribution, motor control centers, transformer protection
• AIC rating: [email protected]
• Class Rating: R
• Barrels: 1
• Weight: 3 lb
• Family: DIN

Product Identification

• UPC: 051712201421
• GTIN: 00051712201421
