Bussmann 155GXQSJD200E - Medium Voltage Fuse 200A ([email protected] Interrupting Capacity)

Bussmann 155GXQSJD200E is a medium voltage current-limiting fuse designed for high-voltage circuit protection in industrial power systems. This Class E rated fuse operates at 15.5kV with a 200A current rating and features a 65kA interrupting capacity at 15.5kV for reliable fault protection. The single-barrel construction utilizes DIN connection compatibility and measures 89mm in diameter with an 18lb weight for robust industrial installation. Certified to Class E standards, this fuse meets rigorous industry requirements for medium voltage applications. Typical implementations include industrial power distribution, motor protection, and transformer circuits where high-voltage interruption capability is critical.

Key Features & Specifications

• Type: Medium voltage current-limiting fuse, Class E rated, single-barrel construction
• Voltage Rating: 15500V AC
• Current Rating: 200A
• Dimensions: 89mm diameter
• Standards: Class E certification
• Applications: Industrial power distribution, motor protection, transformer circuits
• AIC rating: [email protected]
• Connection: DIN
• Barrels: 1
• Class Rating: E
• Weight: 18lb
